We re-designed and optimized the chemical properties of CLIK® Armo plates boasting better performance in cold bending and welding with the protection properties and flatness guaranteed. The fantastic new products have passed the strict tests in the military laboratory. We've also received recognition and appreciatios from the end-users.
CLIK is not only a provider of armor steel plates and components, but also a global supplier of high strength steel and wear-resistant steel plates and components. With our expertise and experience of 25+ years engaged in the steel industry, we have been able to serve you with the right products, right there, right in time.
CLIK® ARMO STEEL PLATE DATA
| Chemical composition content % maximum (ladle analysis) | ||||||||||
| Steel grade | Thickness mm |
C | Si | Mn | P | S | Cr | Ni | Mo | B |
| Clik® Armo 370 | 3 - 25 | 0.13 | 0.40 | 1.40 | 0.02 | 0.010 | 1.50 | 0.40 | 0.40 | 0.005 |
| Clik® Armo 400 | 4 - 40 | 0.20 | 0.70 | 1.70 | 0.03 | 0.015 | 1.50 | 0.40 | 0.50 | 0.004 |
| Clik® Armo 450 | 4 - 40 | 0.26 | 0.60 | 1.50 | 0.03 | 0.015 | 1.50 | 0.70 | 0.50 | 0.005 |
| Clik® Armo 500 | 2.4 - 120 | 0.30 | 0.70 | 1.70 | 0.03 | 0.015 | 1.50 | 0.80 | 0.50 | 0.004 |
| Typical mechanical properties | |||||||||||
| Armo Range | Thickness mm |
Hardness range HBW |
Yield strength Rp 0.2 N/mm2 |
Tensile strength Rm N/mm2 |
Elongation A5% | Impact Charpy-V J @-40°C K |
|||||
| Clik® Armo 370 | 3 - 25 | 320 - 370 | 800 | 1000 | 12 | 20 | |||||
| Clik® Armo 400 | 4 - 40 | 360 - 420 | 1000 | 1250 | 10 | 30 | |||||
| Clik® Armo 450 | 4 - 40 | 420 - 480 | 1200 | 1450 | 8 | 30 | |||||
| Clik® Armo 500 | 2.4 - 120 | 480 - 540 | 1250 | 1600 | 8 | 20 | |||||
| Plate thickness requirments vs. protection levels | ||||||
| EN1522 | ||||||
| Protecion Level | Threat | Muzzle velocity m/s |
Range m |
Armo 450 | Armo 500 | Armo 600 |
| FB5 | 5.56x45 FMJ/PB | 950 ± 10 | 10 | 6.5 | 6.0 | 5.5 |
| FB6 | 5.56x45 FMJ/PB 7.62x51 FMJ/PB/SC |
950 ± 10 830 ± 10 |
10 | 8.0 | 6.5 | 6.0 |
| FB7 | 7.62x51 FMJ/PB/HCI | 820 ± 10 | 10 | 14.5 | 12.0 | |
| STANAG4569 | ||||||
| Protecion Level | Threat | Muzzle velocity m/s |
Range m |
Armo 450 | Armo 500 | Armo 600 |
| Level 1 | 5.56x45 SS109 5.56X45 M193 7.62x51 M80 |
900 ± 20 937 ± 20 833 ± 20 |
30 | 10.0 | 9.5 | 6.5 |
| Level 2 | 7.62x39 API BZ | 695 ± 20 | 30 | 14.0 | 12.0 | |
| Level 3 | 7.62x54R B32 API | 854 ± 20 | 30 | 14.3 | 14.0 | |
CLIK® ARMO STEEL PLATE 370 / 440 / 500 / 600
PROTECTION STEEL PLATES AND COMPONENTS*
DELIVERY CONDITION - Quenched and tempered
TOLERANCES - Dimensions acc. to EN10029 or EN10051 - Thickness acc. to EN10029 class C - Flatness acc. to EN10029 class N, steel type H - Other levels are available on request
SURFACE CONDITION - Acc. to EN10163-2 Class B subclass 3
GENERAL TECHNICAL DELIVERY CONDITION - Acc. to EN10021. Other requirements are available on request
INSPECTION - Acc. to EN10204-2.2. Other requirements are available on request
APPLICATIONS
- Armored personnel carriers
- Riot police vehicles
- Armored cash carriers
- Protective shields
- Wall protection of indoor shooting
- Bank counter shield
- Safe boxes
